Open Source IoT Hardware Platform

IoT Requirement


 Define your Solution

Select Hardware


 Select  Open Hardware Platform

Build Solution


 Use familiar  OpenSource IDE to build custom solution

THE NEXT GENERATION open source controls!

Indino 4.0 series defines a new way of transforming factories into smart/intelligent factories for efficient and easy remote monitoring operational status of facilities such as on/off status, pressure and temperature. Indino 4.0 supporting for wide range of industrial protocols

like Modbus, MQTT, JSON, RESTful, TCP/UDP, SNMP protocol, which makes the monitoring and solution integration, easier than ever for IT engineers through open source APIs.

Operational Benefits


Indino 4.0 can used to build the custom industrial solution for monitoring and

controlling PLC and SCADA, HMI, VFD,Motors, servo, Valves, energy meter,

actuators, relays, encoder, RFID and fingerprint readers, industrial sensors and

many more with below mentioned operational benefits.


  • Improved productivity.
  • Reduced downtime.
  • Maximised asset utilisation.
  • Tracking trends for real-me marketing.
  • Enhanced situational awareness.
  • Sensor-driven decision analytics.
  • Instantaneous control and response in
  • complex autonomous system

Applications




  •  Production and process monitoring.
  • Utilities monitoring.
  •  Condition monitoring.
  •  Environment monitoring.
  •  Industrial Smart grid
  •  Leakage detection.
  •  Cold storage monitoring.
  •  District metering.
  •  Water treatment.
  • Generator monitoring.
  •  Green House.
  • Warning message in case of calamities.
  • Standard SCADA Applications

Features



Processor:

  • Tensilica Xtensa 32-bit LX6 microprocessor
  • Clock frequency: up to 240 MHZ, up to 600 DMIPS
  •  ROM: 448 KB SRAM: 520 KB

Co controller:

  • Atmega 2560, 16MHz, FLASH 256KB / STM32*

Digital IO

  • 24v 8x Isolated  Enabled digital input
  • 24v 1 Amps 4x Isolated Digital output / PWM
  • AC Isolation: 3750VRMS
  • Contacts supported: DRY / WET

Analog IO

  • 0-10v /4-20ma 4x analog input
  • 2/3/4 terminal RTD 1x
  • 2x kType  thermocouple

Wired Connectivity

  • RS485 MODBUS, RS232 & USB, RDL expansion bus
  • Memory: FRAM 25KB, SD CARD 32GB
  • RTC: Built-in RTC for stamped data logging

Wireless connectivity:

  •  Wi-Fi: 802.11 b/g/n/e/i (802.11n up to 150 Mbit/s)
  •  Bluetooth: v4.2 Bluetooth Low Energy (BLE)
  • GPRS / Xbee / LoRA

Protocol:

  • TCP-IP, UDP, SNMP, MODBUS, FTP, RESTFULL,
  • JSON & MQTT

Security:

  •  IEEE 802.11 security features: WFA, WPA/WPA2

and WAPI

  •  Secure boot / Flash encryption
  • 1024-bit OTP, up to 768-bit for customers
  • Cryptography: AES, SHA-2, RSA, ECC & random

number generator (RNG)

Power supply

  • DC 9-30V

Enclosure:

  • IP 20 • Mounting: Wall / DIN Rail
  • Dimension: 108 x 41.2 x 20

Indino 4.0 Products

Indino Digital IO


Indino main block which supporting 8x 24v isolated DIgital INPUT  and 4x 24V  digital OUTPUT / PWM  enabled with WIFI /BLE , RS232,RS485 communication and RTC , SDCARD for real time Data stamping.

Indino Analog IO


Add On Modular blocks for the Indino , for expanding the Analog IO (0-10V/4-20ma), 1x RTD , 2x Thermocouple  and  supporting  RS232, RS485 and 4x DO/PWM.

Indino Ethernet IO


 Add On Modular blocks for the Indino , for expanding the Ethernet IO and  supporting  supporting 6x 24v isolated DIgital INPUT  and 5x 24V  digital OUTPUT

Indino GPRS IO


Add On or independent  blocks  , for expanding the GPRS IO and supporting 8x 24v isolated DIgital INPUT  and 4x 24V  digital OUTPUT / PWM  enabled with  RS232,RS485 communication and RTC , SDCARD for real time Data stamping.

Indino Xbee IO


Add On or independent  blocks , for expanding the XBee IO and  ssupporting 8x 24v isolated DIgital INPUT  and 4x 24V  digital OUTPUT / PWM  enabled with  RS232,RS485 communication and RTC , SDCARD for real time Data stamping.

Indino LoRA IO


Add On or independent  blocks , for expanding the LoRA IO and  supporting 8x 24v isolated DIgital INPUT  and 4x 24V  digital OUTPUT / PWM  enabled with  RS232,RS485 communication and RTC , SDCARD for real time Data stamping.

Automation simplified

Automated Machine Fault Alerting System


Achieve higher productivity and utilization with Industry 4.0 features of Automated Machine Fault Altering system. Enabled with Preventive Analytics using Machine Learning reduces downtime and improves efficiency. Supports Industry Standard Interfaces sensors and interfaces, protocols. Alerts variety of devices and customizable dashboards

Predictive Condition Monitoring System


 Deep Analytics based system, provide insight into prevailing conditions on the Production Floor. Ingests and process data from multiple sensors to deliver actionable intelligent reports. Enable management of large work force with minimal Technical expertise.

Indino 4.0 interfacing with other computing Families

Interfacing Raspberry pi with Indino 4.0


Also Supporting interface for WiFi / BLE and Ethernet communication

Interfacing Intel NUC with Indino 4.0


Also Supporting interface for WiFi / BLE and Ethernet communication

Interfacing BeagleBone with Indino 4.0


Also Supporting interface for WiFi / BLE and Ethernet communication

Open Source Programming IDE

ARDUINO IDE




The open-source Arduino Software (IDE) makes it easy to write code and upload it to the board. It runs on Windows, Mac OS X, and Linux. The environment is written in Java and based on Processing and other open-source software.

(www.arduino.cc)

ATMEL Studio


integrated development platform (IDP) for developing and debugging all AVR® and SAM microcontroller applications. The Atmel Studio 7 IDP gives you a seamless and easy-to-use environment to write, build and debug your applications written in C/C++ or assembly code .(www.atmel.com)'ll check this with

Arduino Compatible Compiler for LabVIEW


 The ArduinoTM compatible compiler for LabVIEWis a compiler that will take a LabVIEW program and compile and download it to ArduinoTM compatible targets. The downloaded code will execute embedded and standalone on the Arduino target (www.tsxperts.com)

ThingSpeak for IoT


ThingSpeak™ is an IoT analytics platform service from MathWorks®, the makers of MATLAB® and Simulink®. ThingSpeak allows you to aggregate, visualize, and analyze live data streams in the cloud. ThingSpeak provides instant visualizations of data posted by your devices or equipment. Execute MATLAB code in ThingSpeak, and perform online analysis and processing of the data as it comes in.

RDL Plug and Play Configuration Manager


At no extra cost every Dataloggger is shipped with Plug and Play Configuration Manager, that  enable configuration of all Input-Output ports across Analog- Digital interfaces and also Communication parameter. Configuration Manager is designed to be operated with minimal training and technical expertise

Soapbox Snap


 SoapBox Snap is a free and open source PC-based automation platform.  It includes a ladder logic editor and a “soft” runtime right out of the box.  The ladder editor includes standard instructions like contacts, coils, timers, counters, rising edge and falling edge, and set/reset instructions.

http://soapboxautomation.com/


OEM & White label Service



RDL OEM (Original Equipment Manufacturer) that designs and builds a product based on their own specification, and then sells it to another company for branding and distribution.

OEM Minimum order quantity 100 to 500 no's.


CUSTOM SOLUTION DEVELOPMENT

Quick adaptability to any kind of customization requirements be it structural, functional, or Look-and-feel. Seamless transformation made possible for every possible aspects to tailor the standard products to realise your creative imagination.


Dynamic Process Support

 Highly Flexible, competitve, and economical solutions encompassing support for wide variety of business domains where customers are sure of getting delightful business deals.

Order Information


Downloads

Code is available on GITHUB

Product Brochure (pdf)

Download

Indino_USER_Manual (pdf)

Download

Shop @ researchdesignlab.com
